HDPE Ground Protection Mat / Temporary Road Mat
HDPE Heavy-Duty Ground Protection Mat – Reusable Anti-Slip Temporary Paving Plate for Construction & Mining Projects
HDPE Ground Protection Mat, also named temporary road mat, bog mat, construction paving plate, is integrally molded with virgin HDPE or UHMWPE raw material. Embossed diamond/herringbone anti-slip texture on surface, interlockable edge design with metal fasteners for quick assembly. It provides stable temporary bearing pavement for heavy machinery on muddy, soft, wet and lawn ground, widely replacing steel plates and timber boards for construction, mining, oilfield, wind power and outdoor event projects globally.
Core Product Features
Modified with anti-UV, anti-oxidant additives, fully compliant with ASTM D638 tensile testing standard, core advantages as below:
- Ultra Lightweight & High Load Bearing Only 1/8 weight of steel plate, 2–3 workers carry single sheet without crane equipment. Standard HDPE mat supports 30–80 tons static load; UHMWPE heavy-duty version bears up to 200 tons, suitable for excavators, dump trucks, cranes and girder transport vehicles, evenly dispersing ground pressure to avoid sinking and rutting on soft foundation.
- Double-Sided Anti-Slip Texture Design Diamond or herringbone raised pattern on both sides greatly improves friction coefficient, effectively preventing vehicle skidding under rainy, muddy, gravel and wet working conditions, guaranteeing construction driving safety.
- Full Resistance to Corrosion & Weather Aging Stable performance at -40℃ ~ +80℃, resistant to acid, alkali, salt, oil, sewage and seawater erosion. No rust, rot, crack or water absorption, service life reaches 10–15 years for repeated turnover use; UV-stabilized black grade supports long-term open-air laying.
- Modular Quick Assembly & Easy Disassembly Reserved bolt holes and matching metal connecting buckles lock adjacent mats tightly, free of welding or concrete fixing. Fast paving and dismantling, convenient for project transshipment, no permanent damage to original ground surface.
- Super Wear & Impact Resistance, Reusable for 50+ Times High molecular structure withstands long-term rolling friction of heavy vehicles and impact from gravel, rocks. Fully recyclable after service cycle, drastically cutting comprehensive project cost compared with steel and wood pavement.
- Eco-Friendly & Ground Protection Zero pollution, no soil contamination. Effectively isolate construction equipment from lawn, wetland and green land, protecting vegetation and reducing later site restoration expenses.
Standard Specifications
Custom size, thickness, color, texture and printed LOGO available upon customer drawings.表格
Dimension (L×W, mm) | Thickness (mm) | Load Capacity (Ton) | Standard Color | Main Application Scenarios |
|---|---|---|---|---|
1220×2440 | 10–18 | 30–50 | Black/Green | Lawn protection, small construction temporary road, event site |
2000×3000 | 20–30 | 50–80 | Black/Yellow | General building site, pipeline construction, material storage yard |
2000×4000 | 30–50 | 80–200 | Black (UHMWPE) | Mining, oilfield, wind turbine platform, heavy haulage access road |
Key Technical IndexWater absorption ＜0.01%; Elongation at break ≥400%; Impact strength ≥25 kJ/m²; UV aging retention ≥70% tensile strength after 500h test.
Wide Application Scenarios
1. Construction & Municipal Engineering
Temporary access road for building sites, foundation pit operation platform, pipeline laying passage, municipal emergency rush repair passage, temporary parking lot for construction vehicles. Solve vehicle trapping problems on muddy low-lying ground.
2. Mining, Oil & Wind Power Industry
Mine haulage road, oil well site ground mat, wind farm equipment transport platform, heap leach pad temporary pavement. Adapt to harsh saline, acidic and muddy mining environments.
3. Water Conservancy & Land Reclamation
Wetland construction passage, river dredging equipment platform, tidal flat reclamation temporary road, reservoir maintenance channel, avoid machinery sinking on soft silt ground.
4. Outdoor Events & Landscape Protection
Large concert, sports game, exhibition temporary walkway and parking lot, golf course, park lawn protection mat, prevent lawn compaction and damage by heavy vehicles.
5. Emergency Rescue Projects
Flood, earthquake disaster emergency access road, fire rescue temporary passage, rapid laying for emergency vehicle passage on damaged muddy ground.
Product Classification
- Standard HDPE Ground Mat (Economy Grade) Virgin HDPE material, balanced cost and performance, for medium-load construction, landscaping and short-cycle turnover projects.
- UHMWPE Heavy-Duty Road Mat (Super Load Grade) Ultra-high molecular weight polyethylene, top-tier wear and impact resistance, high bearing capacity, dedicated to mining, oilfield and super heavy machinery transport.
- UV Stabilized Outdoor Grade Added carbon black anti-UV agent, suitable for long-term open-air exposed laying such as wind farm and open-pit mines.
- Green Lawn Protection Mat Light thin type, low pressure on turf, special for event lawn temporary pavement.
Installation Guidance
- Level the ground before laying, remove sharp stones, steel bars to avoid mat puncture damage.
- Align adjacent mat edge holes, fix with stainless steel connecting buckles to prevent displacement during vehicle rolling.
- For slope construction, add auxiliary ground anchors to lock mats and avoid sliding.
- After project completion, clean mud and gravel on mat surface, stack flat for repeated reuse.
Compliance with International Standards
- Domestic Standard: GB/T 17037 Plastic Molding Materials
- International Test Standards: ASTM D638, ASTM D792
- Certifications: SGS Test Report, CE Certification, ISO 9001 Quality Management System
Our Factory Services
- Customized Production: Adjust dimension, thickness, color, anti-slip pattern and print customer LOGO as required.
- Professional Technical Matching: Provide load calculation and layout scheme according to machinery tonnage and site terrain.
- Stable Fast Delivery: Large injection molding production lines, support FOB/CIF/DAP global trade terms, full container loading.
- Factory Direct Competitive Price: No middlemen, mass production reduces unit cost for bulk orders and rental companies.
- Complete After-Sales Support: Long-term technical follow-up, solve laying and connection problems for global contractors.
